SPUHR Attacchi A-700

A-700 NV Clip-On Adapter

The A-700 NV Clip-On Adapter allows the user to position a clip-on image intensifier in front of – and aligned with – the primary optics of the weapon. The user can adjust the angle of the A-700 from 0 to 13 MIL (0 to 44.4 MOA) as to achieve the same tilt as the ISMS mount the A-700 is being attached to. This minimizes the optical distortion between the image intensifier and the primary optic – thus maximizing target identification and hit probability. Length: 300 mm/11.81” (from face of mount) …………140 mm/5.51” (length of Picatinny) Weight: 200 g/7.0 oz Note: The A-700 is designed for use with the SP-**01 and SP-**02 non-cantilever series of mounts and should not be used on rifles with heavy recoil.Interface for attaching 3rd party accessories with Picatinny clamps to the top and sides of a 34 mm ISMS scope mount. Fits around the front ring on 34 mm mounts. Includes screws. Length: 70 mm/2.76” Weight: 146 g/5.2 oz Note: 34 mm mounts only.
